Double Offset Drop Mount - Single Pin 3x3 Rack
1" Hole / Included (2 Docks)
$195.00
Sale price
$195.00
Regular price
Skip to product information
Double Offset Drop Mount - Single Pin 3x3 Rack
$195.00
Sale price
$195.00
Regular price
Shipping calculated at checkout.
Upright Size (Width × Depth)
The Double Offset Drop Mount is a heavy-duty drop arm designed to offset and lower two VOLTRA units at the same time, attaching to the side of your crossmember or upright on 3x3 power racks. This dual offset drop design delivers greater range of motion and deeper muscle engagement for more effective stretches and stronger contractions on every rep.
Key Features & Specifications:
- Lowers two VOLTRA Is to the bottom of the crossmember or upright for improved pulling angles and range of motion.
- Attaches quickly and securely with a single push pin.
- Designed for 3x3 power racks.
- Supports two VOLTRA units concurrently.
- Predrilled center holes on the backside allow a third DIY Dock to be mounted if desired (two on the ends + one in the center).
- Ideal for use with VOLTRA units on power racks, squat racks, and rigs.
Fitment Note: Please measure your planned installation location carefully before purchasing. The pin-to-VOLTRA I clearance on this mount is approximately 5.5", allowing a wider range of mag pins to fit without impacting the side of the VOLTRA I when locked in the DIY Dock. Mount may be bolted to the rack also.
Important Usage Guidelines:
- Maximum Approved Load for the Mount Drop Arm is equal to the maximum resistance weight of the Beyond Power VOLTRA I unit.
- Not approved for installation of Doubling Plates on the offset DIY Dock locations.
Included with every mount:
- Chafe pad shims for a tighter fit and reduced movement
- Allen wrench for adjustments
Product Contents: This listing is for the Double Offset Drop Mount only. Push pins and DIY Docks are not included unless ordered as an option during checkout. VOLTRA units, doubler plates, and other accessories are sold separately.
Built tough in the USA for serious lifters looking to optimize their VOLTRA I training setup.
Proudly made in the USA.
Specifications
| Length | 15.1875 in |
|---|---|
| Height | 3.4375 in |
| Width | 4.3125 in |
| Weight | 6.4688 lb |
| Weight with DIY Dock | 7.4688 lb |
| Drop | 1.0 in |
| Offset | 3.5625 in |
| Rack fit | 3x3 with 5/8" or 1" push pin (not included) |
| Material | A36 steel, gloss black powder coat |
| Material thickness | 0.313 in |
| Included hardware | 6 × M4-0.7 × 10 mm flat-head socket cap screw 4 × M4-0.7 × 12 mm flat-head socket cap screw |
| Notes | Weight 6 lb 7.5 oz without docks; 7 lb 7.5 oz with two DIY Docks (shown as 6.4688 lb / 7.4688 lb). Length 15 3/16 in; width 4 5/16 in; height 3 7/16 in. Drop is from center of pin to bottom of the mount arm (1 in). Offset is from the face of the mount arm (with the hole) to the center of the DIY dock (3 9/16 in on each side). Pin hole center is 2 7/16 in from the backside of the plate and 1 in from the bottom of the mount arm. Base plate 0.313 in A36; arms (pin passes through) 0.250 in steel. Gloss black powder coat. No M10 doubling hole; no carabiner hole. Clearance from the face of the mounting arm (where the pin hole runs through) to the side of the VOLTRA I when mounted is 1 9/16 in. |
